| Display Parameters |
Concentration, Saturation, Temperature |
| DO |
Range |
0.000 – 90 mg/L (ppm) |
| Resolution |
0.01/0.1 |
| Accuracy |
± 0.5% |
| Saturation |
0.0 – 600% |
| Saturation |
Resolution |
0.10% |
| Accuracy |
±2.0%FS |
| Temperature |
Measuring Range |
(-10~110)℃ |
| Resolution |
0.1℃ |
| Accuracy |
±0.1℃ |
| Compensation Range |
(0 ~ 45)℃ (automatic) |
| Salinity Compensation Range |
(0.0~50.0)g/L |
| Air Pressure |
Compensation Range |
(80 ~ 105)kPa (automatic) |
| Resolution |
1 |
| Accuracy |
± 2% |
| Stability |
(±0.07mg/L)/1h |
| Response Time |
≤30s (25℃, 90% response) |
| Other Parameters |
Display |
6.5-inch LED screen |
| Data Storage |
1000 sets |
| Power |
12V (110-220, 50-60Hz adapter) |
| Communication Interface |
USB, RS232, Bluetooth |
| Size & Weight |
240×170×70mm/600g |
| Working Conditions |
Temperature |
5 ~ 40 ℃ |
| Humidity |
5-85% |
| IP grade |
IP54 |
| Meter Kits |
1) DO meter |
| 2) Electrode holder |
| 3) Two-in-one electrode that consists of DO electrode and temperature probe. |
| 4) DO filling solution |
| 5) Membrane cap |
| 6) Cathode polishing paper |
| 7) Power adapter |
| External Size |
215x170x40mm |
| Shipping Size |
475x430x75mm |
| Net /Gross Weight(kg) |
0.6/3 |
