Floor Freeze Dryer Feature:

7-inch color LCD touchscreen with a user-friendly HMI interface and lock screen function.
Vacuum pump delayed start (activated below the set temperature) to extend service life.
One-touch auxiliary heating/defrosting function for quick recovery.
Axial cooling fan with dual ball bearings for ultra-stable operation and extended service life.
Automatic saving of freeze-drying parameters, supporting data viewing, exporting (USB), deletion, and loss prevention protection.

Floor Freeze Dryer Specification:

Model		FD-18A	FD-18B	FD-18C	FD-18D
Type		Standard	Standard	Standard	Standard
Freeze-dried Area		0.18㎡	0.12㎡	0.18㎡	0.12㎡
Amount of vials of cillin	Φ12mm	1320	920	1320	920
	Φ16mm	698	480	698	480
	Φ22mm	360	260	360	260
Cold Trap Temperature		-60℃
Water Capture KG/batch		6
Standard Vacuum Degree		≦5Pa
Ultimate Vacuum Degree		2PA
Material Tray		240mm 4 layers	220mm 3 layers	240mm 4 layers	220mm 3 layers
Consumption		1300W
Main Unit Weight		100kg
External Size		680x560x880mm
Power Supply		AC220V25A50HZ
Applicable Environment		Ambient temperature ≦30℃
Noise		≦55dB
Accessories		Vacuum pump, 2 KF25 clamps, 1 KF vacuum hose
