Pilot Freeze Dryer Feature:

Compliant with GMP/cGMP standards and equipped with multi-level password protection.
Adjustable vacuum control: manual gas injection or optional automatic regulation.
Intuitive human-machine interface (HMI) supporting menu-guided programming and direct command input.
Multi-level logic interlocks to prevent operational errors.

Pilot Freeze Dryer Specification:

Model		FD-20D	FD-20F	FD-20FT	FD-50F	FD-50FT	FD-100F	FD-100FT
Type		Electrical Heating	Silicone Oil Heating	Gland type silicone oil heating	Silicone Oil Heating	Gland type silicone oil heating	Silicone Oil Heating	Gland type silicone oil heating
Freeze drying area (㎡)		0.2㎡	0.2㎡	0.2㎡	0.5㎡	0.5㎡	1㎡	1㎡
Water capture capacity (kg/batch)		4kg	4kg	4kg	8kg	8kg	15kg	15kg
Amount of vials of cillin	Φ12mm	1300	1300	1300	3690	3690	7380	7380
	Φ16mm	810	810	810	1940	1940	3880	3880
	Φ22mm	430	430	430	1020	1020	2040	2040
Solution (L)		3L	3L	3L	6L	6L	15L	15L
Tray Size	Long(mm)	400	400	300	400	480	480	480
Tray Size	Width(mm)	270	270	345	320	360	360	550
Tray Spacing(mm)		85mm	70mm	70mm	70mm	70mm	60mm	70mm
Number of Tray Layers		2	2+1	2+1	4+1	3+1	6+1	4+1
Tray Temperature Range (°C)		-55℃~60℃	-50℃~60℃	-50℃~60℃	-55℃~60℃	-55℃~60℃	-55℃~60℃	-55℃~60℃
Cold trap minimum temperature (℃)		-70℃	-70℃	-70℃	-80℃	-80℃	-80℃	-80℃
Ultimate vacuum degree (Pa)		1pa	1pa	1pa	1pa	1pa	1pa	1pa
Consumption Kw		2.0Kw (220V)	2.5Kw (220V)	3Kw (220V)	5.0Kw (380V)	5.0Kw (380V)	6.8Kw(380V)	6.8Kw(380V)
Ambient temperature (°C)		≤25℃	≤25℃	≤25℃	≤25℃	≤25℃	≤25℃	≤25℃
External Size (mm)		594×718×1400	800×800×1480	800×800×1480	1200×880×1510	1320x880x1515	1320×880×1580	1400×880×1725
Vacuum Pump		4L/S	4L/S	4L/S	8L/S	8L/S	16L/S	16L/S
Main unit weight		200kg	260kg	260kg	450kg	570kg	560kg	650kg
Package Size		720x840x1650	950x950x1700	950x950x1700	1350x1050x1750	1450x1050x1750	1450x1050x1800	1550x1050x2000
